| General Information |
|---|
| Manufacturer | NEC Display Solutions |
| Manufacturer Part Number | NP-PA500U |
| Manufacturer Website Address | www.necdisplay.com |
| Brand Name | NEC Display |
| Product Series | PA |
| Product Model | NP-PA500U |
| Product Name | NP-PA500U LCD Projector |
| Product Type | LCD Projector |
| Technical Information |
|---|
| Projection Method | Front |
| Projection Method | Rear |
| Projection Method | Ceiling |
| Platform Supported | PC |
| Platform Supported | Mac |
| Lens |
|---|
| Minimum Lens Aperture | F/1.7 |
| Maximum Lens Aperture | F/2.2 |
| Zoom Type | Manual Zoom |
| Manual Zoom Factor | 1.3x |
| Lamp |
|---|
| Lamp Power | 330 W |
| Normal Mode Lamp Life | 3000 Hour |
| Economy Mode Lamp Life | 4000 Hour |
| Image |
|---|
| Standard Mode Brightness | 5000 lm |
| Native Resolution | 1920 x 1200 |
| Graphic Mode | WUXGA |
| Minimum Projection Distance | 29" |
| Maximum Projection Distance | 68.57 ft |
| Diagonal Image Size | 500" |
| Contrast Ratio | 2,000:1 |
| Throw Ratio | 1.5 to 3 |
| Vertical Keystone Correction | -30°/+30° |
| Horizontal Keystone Correction | -35°/+35° |
| Maximum Vertical Sync | 120 Hz |
| Maximum Horizontal Sync | 108 kHz |
| Video |
|---|
| Video Signal Format | NTSC |
| Video Signal Format | PAL |
| Video Signal Format | SECAM |
| Video Signal Standard | HDTV |
| Input Scan Format | 1080p |
| Output Scan Format | 1080p |
| Audio |
|---|
| Number of Speakers | 1 |
| Speaker Output Power | 10 W |
| Speaker Output Mode | Mono |
| Interfaces/Ports |
|---|
| HDMI | Yes |
| USB | Yes |
| VGA | Yes |
| Composite Video | Yes |
| Component Video | Yes |
| Power Description |
|---|
| Input Voltage | 110 V AC |
| Input Voltage | 220 V AC |
| Operating Power Consumption | 477 W |
| Standby Power Consumption | 200 mW |
| Physical Characteristics |
|---|
| Height | 6.1" |
| Width | 19.6" |
| Depth | 14.1" |
| Weight (Approximate) | 17.64 lb |
| Miscellaneous |
|---|
| Certifications & Standards | USA UL 1950 FCC Class B Canada CSA950 (C-UL) NOM |
| Warranty |
|---|
| Standard Warranty | 3 Year |
| Parts Warranty/Labor | 1 Year - Lamp |
Marketing Information
Integrated Device Technology HQV is a high-performance video processing/scaling system designed for computer signals as well as standard or high-definition video. The technology produces superior video processing using pixel-based, motion- adaptive de-interlacing to remove undesirable motion artifacts typical of interlaced signals. This processing creates life-like images in applications such as video conferencing.
