| General Information |
|---|
| Manufacturer | American Power Conversion Corp |
| Manufacturer Part Number | AP7899 |
| Manufacturer Website Address | www.apc.com |
| Brand Name | APC |
| Product Line | Metered Rack |
| Product Name | Metered Rack 14.4kW PDU |
| Product Type | PDU |
| Technical Information |
|---|
| Input Receptacles | Hubbell CS8365C |
| Output Receptacles | 24 x IEC 320-C13 |
| Output Receptacles | 4 x IEC 320-C19 |
| Output Receptacles | 2 x NEMA L6-30R |
| Protection Type | Overload Protection |
| Power Description |
|---|
| Input Voltage | 208 V AC Three-phase |
| Output Voltage | 208 V AC |
| Current | 40 A Total Current Draw Per Phase |
| Current | 50 A Input Current Per Phase |
| Frequency | 47 Hzto 63 Hz |
| Power Rating | 14.40 kVA |
| Controls/Indicators |
|---|
| Status Indicators | Load Indicator LED |
| Environmental Conditions |
|---|
| Temperature | 23°F (-5°C) to 113°F (45°C) Operating |
| Temperature | -13°F (-25°C) to 149°F (65°C) Storage |
| Humidity | 5 to 95% Operating |
| Humidity | 5 to 95% Storage |
| Altitude | 0 ft to 10000 ft Operating |
| Altitude | 0 ft to 50000 ft Storage |
| Physical Characteristics |
|---|
| Color | Black |
| Form Factor | Zero U |
| Power Cord/Cable | 10 ft |
| Dimensions | 70.0" Height x 2.2" Width x 3.8" Depth |
| Weight (Approximate) | 22.80 lb |
| Miscellaneous |
|---|
| Additional Information | Alarm Thresholds Flash Upgradeable High Power Density Information Displays Local Current Monitoring Display Network Management Remote Current Monitoring Toolless Mounting Capability Vertical Mounting Capability |
| Certifications & Standards | cUL Listed CSA FCC Part 15 Class A ICES-003 Industry Canada METI Denan UL 60950 UL Listed |
| Warranty |
|---|
| Standard Warranty | 2 Year |
Marketing Information
The American Power Conversion (APC) Metered Rack Power Distribution Unit (PDU) distributes power to devices in the rack. It has a sensor that measures the current that it and its attached devices use. It can be monitored through Web, Telnet, SNMP, SSH, or InfraStruXure Manager interfaces.
